北京君正T01
君正T01
|
|
|
芯片框图
君正代理芯片规格
| CPU | XBurst®-1 core 600MHZ/1GHZ – XBurst® RISC instruction set – XBurst® SIMD128 instruction set – XBurst® FPU instruction set supporting both single and double floating point format which are IEEE754 compatible – XBurst® 9-stage pipeline micro-architecture, the operating frequency is 800MHz |
| Memory | Integrated DDR |
| Spirit engine | More than 10 people realtime multi-detection. Max input resolution 2048x2048 @60fps. |
| Video input/output | Video input – DVP Input data format: YUV422, RGB565, RGB555, RAW8, RAW10, RAW12. – BT656/BT1120 – MIPI CSI2 IN (Ingenic Host Soc Only) Video output – MIPI CSI2 OUT (Ingenic Host Soc Only) |
| Result output | Synchronous serial slave interfaces (SSI_SLV) – 3 protocols support: Motorola’s SPI, TI’s SSP and National’s Microwire – Full-duplex, transmit-only or receive-only operation for Motorola’s SPI and TI’s SSP – Half-duplex, transmit-only or receive-only operation for National’s Microwire USB 2.0 interface – Complies with the USB 2.0 standard for high-speed (480 Mbps) functions and with the On-The-Go supplement to the USB 2.0 specification – Operates either as the function controller of a high- /full-speed USB peripheral or as the host/peripheral in point-to-point or multi-point communications with other USB functions – 16 Endpoints: – Dedicate FIFO – Supports control, interrupt, ISO and bulk transfer |
